| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
100 pcs
|
100 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Bandwidth | |
| Operating Temperature | |
| Output Type |
The AD8515ARTZ-R2 is a general-purpose operational amplifier manufactured by AD(RoHS). This component is designed for a wide range of applications, offering a 5MHz bandwidth and a Rail-to-Rail output stage. It supports single or dual supply voltages from 1.8V to 5V, making it versatile for various circuit designs.
The operational amplifier features a low input bias current of 5pA and a supply current of 410µA. It operates within an extended temperature range of -40°C to 125°C. The device is supplied in a compact SC-74A, SOT-753 package, often referred to as TSOT23-5, suitable for space-constrained applications.
This component is suitable for applications requiring precise signal amplification and low power consumption. Its specifications make it a good choice for signal conditioning, active filters, and other analog circuit designs where performance and size are critical.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.20 | $1.20 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The operating temperature range for the AD8515ARTZ-R2 is -40°C to 125°C.
The AD8515ARTZ-R2 offers a Rail-to-Rail output type.
The AD8515ARTZ-R2 operates with a supply voltage range of 1.8 V to 5 V.
The input bias current for the AD8515ARTZ-R2 is 5pA.
The supply current for the AD8515ARTZ-R2 is 410µA.
The bandwidth of the AD8515ARTZ-R2 operational amplifier is 5MHz.
The AD8515ARTZ-R2 is supplied in a SC-74A, SOT-753 package, also referred to as TSOT23-5.
