The AD7243BR from Analog Devices is a versatile 12-bit, voltage-output digital-to-analog converter (DAC). It integrates an output amplifier and a Zener voltage reference on a single monolithic CMOS chip, eliminating the need for external trims.
This DAC supports three selectable output voltage ranges: -5 V to +5 V, 0 V to +5 V, and 0 V to +10 V. It features a serial interface allowing easy connection to microcomputers and DSPs, with a DAC update rate of up to 300 kHz. The nonlinearity is specified at 0.5 LSB across the operating temperature range.
The AD7243BR is fabricated using LC2MOS technology and is available in 16-lead DIP and SOIC packages. Its low power dissipation of typically 100 mW makes it suitable for various applications.
Applications include process control, industrial automation, digital signal processing systems, and input/output ports where precise voltage conversion is required.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.01 | $2.01 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The AD7243BR offers three selectable output voltage ranges: -5 V to +5 V, 0 V to +5 V, and 0 V to +10 V.
The AD7243BR has a DAC update rate of 300 kHz.
The nonlinearity of the AD7243BR is 0.5 LSB from minimum to maximum temperature.
The typical power dissipation for the AD7243BR is 100 mW.
The AD7243BR is available in 16-lead DIP and 16-lead SOIC packages.
