AD246JN AD246JN is a 25 kHz clock buffer/driver from Analog Devices. It features a 1:1 ratio, 15V supply, and 32 fan-out, housed in a 24-DIP package.
Mfr Part #:

AD246JN

Available from 1 distributors
Mfr Name: Analog Devices / Maxim Integrated
Analog Devices / Maxim Integrated
AD246JN is a 25 kHz clock buffer/driver from Analog Devices. It features a 1:1 ratio, 15V supply, and 32 fan-out, housed in a 24-DIP package.
✓ Total Stock: 1,700 pcs

AD246JN Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Components Technology Group, Inc. ✓
Non-Authorised Inventory information
1,700 pcs
On Request
1700 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

AD246JN Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Differential
Frequency
Input
Mounting Type
Number of Circuits
Operating Temperature
Output
Ratio
Supplier Device Package
Type
Voltage
View Similar Products (0)

AD246JN Description

Short technical summary and product information.

The AD246JN is a compact clock driver designed to generate a 25 kHz clock signal from a single 15V supply. It can drive up to 32 AD204 isolators, making it suitable for applications requiring multiple synchronized clocks. The device operates over a supply range of 14.25V to 15.75V and draws a typical supply current of 35 mA unloaded. The output provides a 15V p-p clock signal with a maximum fan-out of 32 loads. The AD246JN is housed in a 24-DIP (0.500", 12.70mm) package with 4 leads, through-hole mounting, and operates over -40°C to +85°C. It is listed as RoHS3 compliant, though this status is unverified. The device is designed for use with the AD204 isolator family and includes internal bypass capacitance.

AD246JN Quick Information

Product Type: Clock Buffer/Driver
Canonical Name: AD246JN Clock Buffer/Driver
Subcategory: Clock Buffers, Drivers

AD246JN Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

AD246JN Features

  • 25 kHz nominal clock frequency.
  • Supports up to 32 fan-out loads.
  • Single 15V supply operation.
  • Through-hole 24-DIP package.
  • Wide operating temperature range -40°C to +85°C.

AD246JN Applications

  • Serves as clock driver for AD204 isolators.
  • Drives up to 32 AD204 isolation amplifiers.
  • Provides clock signal from single 15V supply.
  • Buffers clock for multiple isolation amplifiers.

AD246JN FAQs

7 frequently asked questions generated from this part’s specifications.
What is the supply voltage range for the AD246JN?

14.25V to 15.75V.

What is the package type of the AD246JN?

24-DIP (0.500", 12.70mm) with 4 leads, through-hole.

What is the operating temperature range?

-40°C to +85°C.

Is the AD246JN RoHS compliant?

The part is listed as RoHS3 compliant, but this status is unverified.

What is the frequency of the clock output?

25 kHz nominal.

What is the maximum fan-out?

32 loads.

What is the ratio of input to output?

1:1.
