| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
112 pcs
|
112 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Bearing Type | |
| Dimensions | |
| Operating Voltage | |
| Power Consumption | |
| Rated Current | |
| Static Pressure | |
| Termination | |
| Weight |
This ADDA AD0612LB-A76GL is a DC Axial Fan designed for efficient cooling in electronic devices. It operates at a nominal voltage of 12V and features a rated current of 0.08A with a power consumption of 0.96W.
The fan has a nominal speed of 2,800 RPM, delivering an airflow of 32.0 m³/h (18.8 CFM) and a static pressure of 15.2 Pa. It utilizes a durable Ball Bearing system for reliable operation and has a low noise level of 21.5 dB(A).
With dimensions of 60x60x25 mm, this fan is suitable for spot cooling applications in network routers, small servers, and industrial control cabinets. The 3-wire termination provides Tachometer Output (FG) functionality for speed monitoring and closed-loop control.
The frame and impeller are constructed from Plastic (PBT) for durability. Safety approvals include CE and TUV, and it is RoHS compliant.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.00 | $2.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
12 V.
0.08 A.
32 m³/h (18.8 CFM).
21.5 dB(A).
Ball Bearing.
60 x 60 x 25 mm.
3-Wire Leads (Tachometer Output).
