AD-155A The Mean Well AD-155A is an enclosed chassis-mount AC/DC converter delivering 152W with dual outputs of 13.8V and 13.3V (500mA on secondary). It features adjustable output and universal input for commercial ITE applications.
Mfr Part #:

AD-155A

Available from 1 distributors
Mfr Name: Mean Well USA
Mean Well USA
The Mean Well AD-155A is an enclosed chassis-mount AC/DC converter delivering 152W with dual outputs of 13.8V and 13.3V (500mA on secondary). It features adjustable output and universal input for commercial ITE applications.
✓ Total Stock: 100 pcs

AD-155A Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
AA2DE ✓
Non-Authorised Inventory information
100 pcs
On Request
100 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

AD-155A Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Applications
Approval Agency
Current
Efficiency
Features
Height
Length
Mounting Type
Number of Outputs
Operating Temperature
Power
Power (Watts)
Storage Temperature
Type
Voltage
Width
View Similar Products (0)

AD-155A Description

Short technical summary and product information.

The Mean Well AD-155A is an enclosed AC/DC converter designed for commercial ITE (Information Technology Equipment) applications. It delivers a total output power of 152W with two outputs: a main 13.8V and a secondary 13.3V rated at 0.5A. The converter achieves 80% efficiency and includes adjustable output and universal input features.



The converter is housed in an enclosed chassis-mount package measuring 199.0mm x 110.0mm x 50.0mm (7.83" x 4.33" x 1.97"). It operates over a temperature range of -10°C to 60°C with derating, making it suitable for various ambient conditions. Safety approvals include CB, CE, cURus, and TUV, and the device is declared RoHS3 Compliant and REACH Unaffected.

AD-155A Quick Information

Product Type: AC/DC Converter
Series: AD-155
Canonical Name: Mean Well USA AD-155A AC/DC Converter, Enclosed, Chassis Mount, 152W, Dual Output 13.8V and 13.3V
Subcategory: Enclosed

AD-155A Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 10
REACH Status: REACH Unaffected
Lead Free: Yes

AD-155A Features

  • Dual output 13.8V and 13.3V.
  • 152W total output power.
  • Enclosed chassis mount design.
  • Adjustable output voltage.
  • 80% typical efficiency.

AD-155A Applications

  • Used in commercial ITE (Information Technology Equipment) applications.
  • Suitable for industrial power supplies.
  • Ideal for distributed power architectures.

AD-155A FAQs

7 frequently asked questions generated from this part’s specifications.
What is the output voltage of the AD-155A?

Dual outputs: 13.8V (main) and 13.3V (secondary, 0.5A).

What is the operating temperature range?

-10°C to 60°C with derating.

Is the AD-155A RoHS compliant?

RoHS3 Compliant (unverified).

What is the package type?

Enclosed, chassis mount.

What is the power rating?

152W.

What is the efficiency?

80%.

What approvals does the AD-155A hold?

CB, CE, cURus, TUV.
