The Allegro MicroSystems ACS726LLFTR-20B-T is an open-loop, Hall effect current sensor capable of measuring AC and DC currents up to 20A. It provides a ratiometric voltage output and features a sensitivity of 100mV/A with an accuracy of ±1% and linearity of ±0.5%.
Designed for efficient operation, this sensor requires a supply voltage between 3V and 3.6V and has a maximum supply current of 40mA. It operates across a wide temperature range of -40°C to 150°C and has a fast response time of 5µs. The sensor supports bidirectional current flow and operates at frequencies from DC up to 120kHz.
This component is housed in a 24-SSOP package with a surface mount type, making it suitable for various PCB designs. The package dimensions are 0.154" (3.90mm) in width. It is classified under the Current Sensors category and is manufactured by Allegro MicroSystems.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.50 | $1.50 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The ACS726LLFTR-20B-T can sense currents up to 20A.
It is a Hall Effect, Open Loop sensor.
The output is Ratiometric, Voltage.
The accuracy is ±1%.
The supply voltage range is 3V to 3.6V.
The operating temperature range is -40°C to 150°C.
It is supplied in a 24-SSOP package.
