Mfr Part #:

ACM2004G-NLW-BTW

Name: ACM2004G-NLW-BTW
Brand: AZ Displays
SKU: ACM2004G-NLW-BTW

Mfr Name: AZ Displays

Description:

20X4 CHARACTER LCD TRANSMISSIVE

Stock on Request

ACM2004G-NLW-BTW Description

Short technical summary and product information.

20X4 CHARACTER LCD TRANSMISSIVE

Mfr Standard Lead Time: 12 weeks (varies by distributor)

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

Category	Display Modules - LCD, OLED Character and Numeric
Manufacturer Name	AZ Displays
Backlight	LED
Character Format	5 x 8 Dots
Character Size	4.75mm H x 2.95mm W
Controller Type	KS0066
Display Format	20 x 4
Display Mode	Transmissive
Display Type	STN - Super-Twisted Nematic, TN - Twisted Nematic
Dot Size	0.55mm W x 0.55mm H
Operating Temperature	-20°C ~ 70°C
Outline L x W x H	98.00mm x 60.00mm x 14.00mm
Viewing Area	76.00mm L x 25.20mm W
Voltage	2.7V ~ 5.5V
