The Cosel AC6-OEC2H-00 is a high-performance AC-DC power supply from the ACE series, delivering up to 650W of total output power. It features a flexible modular system architecture with three distinct outputs: 24V at 14A, 5V at 26A, and 12V at 13A. This converter supports a universal input voltage range of 85-264 VAC, making it suitable for global applications.
Designed for reliability and efficiency, the AC6-OEC2H-00 boasts up to 80% efficiency and includes Power Factor Correction (PFC) compliant with IEC61000-3-2. It operates within a wide temperature range of -20°C to 70°C and meets various safety and EMI standards, including UL60950-1, EN62368-1, and FCC-B.
With its enclosed type and chassis mount, this power supply is ideal for integration into industrial, commercial, and medical equipment. It also offers features like remote ON/OFF control and alarm functions for enhanced system management.
Channel 1: 24 VDC at 14 A; Channel 2: 5 VDC at 26 A; Channel 3: 12 VDC at 13 A.
85-264 VAC, 47-63 Hz. A DC input option (120-350 VDC) is also available.
-20°C to +70°C.
UL60950-1, C-UL (CSA60950-1), EN62368-1. Optional medical approvals: UL60601-1, C-UL (CSA601.1), EN60601-1.
278.9 mm x 127.0 mm x 63.5 mm; maximum weight 2.4 kg.
Yes, it complies with IEC61000-3-2.
