The Cosel AC6-FFC2C-02 is a versatile AC/DC converter designed for industrial and commercial applications. It provides a total output power of 650W across four separate outputs, with specific voltages and currents detailed in the product specifications.
This converter features a flexible modular system architecture and a universal input voltage range of AC85 - 264V, ensuring compatibility worldwide. It includes essential features like Power Factor Correction and Harmonic Attenuator compliance with IEC61000-3-2. The unit is designed for chassis mounting and operates within a wide temperature range of -20°C to +70°C.
Safety and compliance are paramount, with approvals from agencies such as CE, CSA, cURus, TUV, and UL. It meets standards including EN60950-1, UL60950-1, EN62368-1, and UL60601-1 (optional), making it suitable for ITE (Commercial) and Medical applications. The enclosed type offers robust protection for demanding environments.
The input voltage range is 85-264 VAC at 47-63 Hz.
The converter provides four outputs: 5V/60A, 5V, 15V/10A, and 5V. Total power is 650W.
The operating temperature range is -20 to +70°C.
Yes, it includes power factor correction and a harmonic attenuator.
Input-to-output isolation is 3,000 VAC, input-to-ground is 2,000 VAC, and output-to-ground is 500 VAC.
Efficiency is typical 80% at full load.
It is CE and UKCA marked. RoHS and REACH compliance is listed but unverified.
