Mfr Part #:

AC220TD2424DG-30W

The HenLv Power AC220TD2424DG-30W is a 30W AC DC converter with a 24V output voltage. It operates from an input voltage range of 85-305 VAC and has an efficiency of 72%.

Stock on Request

AC220TD2424DG-30W Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	AC DC Converters
Manufacturer Name	HenLv Power
Dimensions	72.0mm x 50.0mm x 25.0mm
Efficiency	72%
Input Voltage	85 ~ 305 VAC
Output Voltage	24V
Power (Watts)	30W
Voltage	3000V

View Similar Products (0)

AC220TD2424DG-30W Description

Short technical summary and product information.

This AC DC converter from HenLv Power, part number AC220TD2424DG-30W, provides a reliable power solution with 30W of power and a 24V output.

It is designed to accept a wide input voltage range of 85 to 305 VAC, making it suitable for various global applications. The converter boasts an efficiency rating of 72%, ensuring effective power conversion. Its dimensions are 72.0mm in length, 50.0mm in width, and 25.0mm in height.

The AC220TD2424DG-30W is categorized under AC DC Converters, a subset of Power Supplies. Its specifications indicate a high isolation voltage of 3000V.

This component is suitable for applications requiring a stable 24V DC output from an AC or DC input source. The compact size facilitates integration into various electronic systems.

AC220TD2424DG-30W Quick Information

Product Type: AC DC Converter

Series: AC220TD

Canonical Name: AC DC Converter

Subcategory: AC DC Converters

AC220TD2424DG-30W Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

AC220TD2424DG-30W Features

30W power output capability.
Stable 24V DC output voltage.
Wide 85-305 VAC input range.
72% power conversion efficiency.
Compact dimensions of 72.0x50.0x25.0mm.

AC220TD2424DG-30W Applications

Suitable for various global power inputs.
Ideal for systems needing 24V DC.
Used in compact electronic designs.
Reliable power conversion applications.

AC220TD2424DG-30W FAQs

6 frequently asked questions generated from this part’s specifications.

What is the input voltage range of the AC220TD2424DG-30W?

The input voltage range is 85 to 305 VAC.

What is the output voltage of this converter?

The output voltage is 24 VDC.

What is the power rating of the AC220TD2424DG-30W?

The power rating is 30W.

What is the efficiency of this AC DC converter?

The efficiency is 72%.

What is the isolation voltage of the AC220TD2424DG-30W?

The isolation voltage is 3000V.

What are the dimensions of the AC220TD2424DG-30W?

The dimensions are 72.0mm x 50.0mm x 25.0mm.
