Mfr Part #:

AC220S05DC-100WFC

The HenLv Power AC220S05DC-100WFC is an AC DC converter with a wide input voltage range. It features 20A output current and 77% efficiency.

Stock on Request

AC220S05DC-100WFC Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	AC DC Converters
Manufacturer Name	HenLv Power
Current	20A
Efficiency	77%
Height	27.0mm (1.06")
Length	76.2mm (3.00")
Voltage	85 ~ 305 VAC
Width	76.2mm (3.00")

View Similar Products (0)

AC220S05DC-100WFC Description

Short technical summary and product information.

The HenLv Power AC220S05DC-100WFC is an AC DC converter designed for board mount applications. It operates with an input voltage range of 85 to 305 VAC or 120 to 430 VDC, providing a stable output.

Key electrical specifications include an output current of 20A and an efficiency rating of 77%. The converter has dimensions of 76.2mm x 76.2mm x 27.0mm. It is compliant with RoHS3 standards and has an MSL rating of 1.

This AC DC converter is suitable for various industrial control and power source applications where reliable power conversion is essential. Its wide input voltage range makes it versatile for different power grid requirements.

AC220S05DC-100WFC Quick Information

Product Type: AC DC Converter

Canonical Name: AC DC Converter

Subcategory: AC DC Converters

AC220S05DC-100WFC Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

AC220S05DC-100WFC Features

Wide input voltage range 85-305 VAC.
High output current of 20A.
77% efficiency for power conversion.
Compact dimensions of 76.2mm x 76.2mm x 27.0mm.
RoHS3 compliant for environmental standards.

AC220S05DC-100WFC Applications

Suitable for board mount applications.
Ideal for industrial control systems.
Used in various power source designs.
Reliable for communication devices.

AC220S05DC-100WFC FAQs

4 frequently asked questions generated from this part’s specifications.

What is the input voltage range for the AC220S05DC-100WFC?

The input voltage range is 85 to 305 VAC or 120 to 430 VDC.

What is the output current of the AC220S05DC-100WFC?

The output current is 20A.

What is the efficiency of the AC220S05DC-100WFC?

The efficiency is 77%.

What are the dimensions of the AC220S05DC-100WFC?

The dimensions are 76.2mm x 76.2mm x 27.0mm.
