Mfr Part #:

AC220D12DC-15W

The HenLv Power AC220D12DC-15W is an AC DC converter offering +12V/-12V output and 15W of power. It features a wide input voltage range and 79% efficiency.

Stock on Request

AC220D12DC-15W Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	AC DC Converters
Manufacturer Name	HenLv Power
Current	625mA
Efficiency	79%
Height	22.0mm (0.87")
Length	62.0mm (2.44")
Voltage	85 ~ 305 VAC
Width	45.0mm (1.77")

View Similar Products (0)

AC220D12DC-15W Description

Short technical summary and product information.

This AC DC converter from HenLv Power, part number AC220D12DC-15W, provides a dual output of +12V and -12V with a total power of 15W. It operates with a broad input voltage range of 85 to 305 VAC or 120 to 430 VDC, making it suitable for various power applications.

The converter boasts an efficiency of 79% and delivers an output current of 625mA. Its dimensions are 62.0mm in length, 45.0mm in width, and 22.0mm in height, suitable for board mount applications.

Compliance information indicates RoHS3 compliance, Moisture Sensitivity Level 1, and REACH unaffected status. These specifications make it a versatile component for power supply designs requiring reliable AC to DC conversion.

AC220D12DC-15W Quick Information

Product Type: AC DC Converter

Canonical Name: AC DC Converter, +12V/-12V, 15W

AC220D12DC-15W Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

AC220D12DC-15W Features

AC DC converter with +/-12V output.
15W total power output.
Wide 85-305 VAC input voltage.
79% efficiency.
Compact 62.0 x 45.0 x 22.0 mm size.

AC220D12DC-15W Applications

Ideal for industrial control system power supplies.
Used in dual-rail op-amp circuits.
Suitable for telecom equipment power distribution.
Powers sensors and transmitters in automation.
Applicable for test and measurement instruments.

AC220D12DC-15W FAQs

6 frequently asked questions generated from this part’s specifications.

What is the input voltage range for the AC220D12DC-15W?

The input voltage range is 85 to 305 VAC or 120 to 430 VDC.

What is the output current of the AC220D12DC-15W?

The output current is 625mA.

What is the efficiency of the AC220D12DC-15W converter?

The efficiency is 79%.

What are the dimensions of the AC220D12DC-15W?

The dimensions are 62.0mm x 45.0mm x 22.0mm.

Is the AC220D12DC-15W RoHS compliant?

The RoHS Status is RoHS3 Compliant.

What is the Moisture Sensitivity Level (MSL) for this part?

The Moisture Sensitivity Level is 1 Unlimited.
