| Category | |
| Manufacturer Name | |
| Actuator Type | |
| Approval Agency | |
| Breaker Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Dimensions | |
| Illumination | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Poles | |
| Standards | |
| Termination | |
| Termination Style | |
| Voltage Rating |
This Littelfuse Inc. AC1-B0-34-625-1G1-C is a 1-pole circuit breaker designed for reliable electrical protection. It offers a current rating of 25A and a voltage rating of 277VAC, with an additional 80VDC rating.
The breaker utilizes a rocker actuator for operation and features a magnetic hydraulic overload mechanism with a medium delay trip time. Its specifications include a dielectric strength of 1500V and an insulation resistance of 100 MegaOhms. The operating temperature range is from -40°C to 85°C.
Mounting is designed for panels or chassis rear mount, with a specific mounting hole size of 0.156 inches. Termination is achieved via QC tabs. The circuit breaker is recognized by CSA and UL standards, indicating compliance with safety regulations.
Environmental compliance includes RoHS3 status, MSL 1, and REACH unaffected. This component is suitable for applications requiring robust circuit protection in industrial and potentially telecommunications or marine environments, as suggested by its application notes.
The current rating is 25A.
The voltage rating is 277VAC and 80VDC.
This circuit breaker has 1 pole.
It uses a rocker actuator.
The operating temperature range is -40°C to 85°C.
Yes, it is RoHS3 Compliant.
