The ARCH ABR300-48S is a high-power AC/DC converter designed for industrial and commercial applications. It delivers 300 Watts of power with a stable 48VDC output voltage and a maximum current of 6.25A.
This converter operates with a universal input voltage range of 90-264 VAC and features Active PFC for improved power efficiency, reaching up to 91% at 230VAC. Key electrical specifications include ±2% voltage accuracy, ±1% line and load regulation, and a maximum ripple and noise of 300mV.
Designed for reliability, the ABR300-48S includes Over Current, Over Voltage, Over Temperature, and Short Circuit protections, all with auto-recovery features. It also offers Remote Sense capability for precise output voltage control. The operating temperature range is -40°C to 100°C on the base plate, and it boasts an MTBF of over 250,000 hours at 25°C.
The unit is housed in a full brick package with dimensions of 117.2mm x 61.4mm x 13.2mm and is designed for conduction cooling. Mounting is via Through Hole, and it carries CE and cURus safety agency approvals.
90-264 VAC.
48V DC.
6.25A.
91%.
-40°C to 100°C.
11-DIP Module, through-hole mounting.
3000 VAC.
