| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
19 pcs
|
19 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| ESR (Equivalent Series Resistance) | |
| Frequency | |
| Frequency Stability | |
| Frequency Tolerance | |
| Halogen Free | |
| Height | |
| Length | |
| Load Capacitance | |
| Mounting Type | |
| Operating Mode | |
| Operating Temperature | |
| Package / Case | |
| Type | |
| Width |
The ABLS-8.000MHZ-12-B-4-Y-T is an 8 MHz fundamental mode quartz crystal from Abracon’s ABLS series. It is designed for surface-mount applications and comes in a compact HC-49/US package measuring 11.4 mm x 4.7 mm x 4.2 mm. Key electrical specifications include a load capacitance of 12 pF, a maximum equivalent series resistance (ESR) of 80 Ω, and a frequency tolerance and stability of ±30 ppm over the operating temperature range of -20°C to +70°C. The crystal operates in fundamental mode with a typical drive level of 100 μW. This component is suitable for use in computers, modems, microprocessors, and wireless communication devices. It is RoHS compliant and has an MSL rating of 1 (unlimited). The ABLS series offers tight stability and extended temperature range options, making it a versatile choice for timing applications.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.25 | $0.25 |
| 10+ | $0.22 | $0.22 |
| 25+ | $0.21 | $0.21 |
| 50+ | $0.20 | $0.20 |
| 100+ | $0.19 | $0.19 |
| 250+ | $0.18 | $0.18 |
| 500+ | $0.17 | $0.17 |
| 1,000+ | $0.16 | $0.16 |
| 2,000+ | $0.16 | $0.16 |
| 3,000+ | $0.15 | $0.15 |
| 5,000+ | $0.15 | $0.15 |
| 7,000+ | $0.15 | $0.15 |
| 10,000+ | $0.14 | $0.14 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
8 MHz.
12 pF.
HC-49/US surface-mount package.
-20°C to 70°C.
RoHS3 Compliant (unverified, low confidence).
80 Ω maximum.
±30 ppm.
