The AAS-AQS-UNO is an evaluation board from Amphenol Advanced Sensors designed for rapid prototyping of air quality sensor systems. It is based on an Arduino-compatible platform with preloaded software, allowing developers to evaluate Telaire sensors including T9602 temperature/humidity, T6713 CO2, and SM-PWM-01C dust sensors. The board supports additional interfaces for laser dust sensors and an OLED display.
Key specifications include a 5V DC power supply with 1A current rating, operating temperature range of 0°C to 60°C, and humidity range of 0% to 95% RH. The board provides digital outputs with low level <0.8V and high level >2.7V at 3.3V logic. Communication interfaces include I²C, UART, and PWM depending on the sensor configuration.
The evaluation kit includes the main board, sensor shield, USB cable, OLED screen, and an SM-PWM-01C dust sensor. The board dimensions are 72 mm x 56 mm. Sample code is available on GitHub for quick start development.
| Qty | Low | High |
|---|---|---|
| 1+ | $51.27 | $51.27 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The AAS-AQS-UNO operates at a rated DC power supply voltage of 5V.
The operating temperature range is 0°C to 60°C.
The RoHS status is listed as RoHS3 Compliant, but this is unverified from source documents.
The board supports T9602 temperature/humidity sensors, T6713 carbon dioxide sensors, SM-PWM-01C dust sensors, and additional laser dust and infrared dust sensors.
The board supports I²C (for T9602), UART (for T6713 and laser dust), and PWM (for infrared dust) interfaces.
The rated DC power supply current is 1A.
The board dimensions are 72 mm x 56 mm.
