| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
This Delta Electronics AA60S2400A is an enclosed AC/DC converter designed for ITE (Commercial) applications. It provides a power output of 60W and a current rating of 2.5A.
The converter accepts a wide input voltage range of 85 to 264 VAC, ensuring versatility in different power environments. It features universal input and has an efficiency of 84%.
With a through-hole mounting type, the AA60S2400A has dimensions of 88.9mm in length, 67.5mm in width, and 34.2mm in height. It operates within a temperature range of -10°C to 70°C with derating and complies with standard 60950-1. The unit is RoHS3 Compliant and has an MSL of 1.
85 to 264 VAC.
6-DIP Module with 4 leads.
-10°C to 70°C with derating.
84%.
2.5A.
60W.
CE and UL, standard 60950-1.
