AA3528AZGC The Kingbright AA3528AZGC is a green LED with a clear, colorless lens. It features a surface mount 2-PLCC package and is suitable for SMT assembly.
Mfr Part #:

AA3528AZGC

Available from 1 distributors
Mfr Name: Kingbright
Kingbright
The Kingbright AA3528AZGC is a green LED with a clear, colorless lens. It features a surface mount 2-PLCC package and is suitable for SMT assembly.
✓ Total Stock: 1,500 pcs
$ Price Range: $0.99

AA3528AZGC Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Braun Electronic Components ✓
Non-Authorised Inventory information
1,500 pcs
On Request
1500 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

AA3528AZGC Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Capacitance
Color
Configuration
Current
Height (Max)
Lens Color
Lens Size
Lens Style
Lens Transparency
Millicandela Rating
Mounting Type
Operating Temperature
Peak Forward Current
Power Dissipation
Reverse Current
Reverse Voltage
Storage Temperature
Supplier Device Package
Viewing Angle
Voltage
Wavelength
View Similar Products (0)

AA3528AZGC Description

Short technical summary and product information.

This Kingbright AA3528AZGC is a single-color green LED designed for surface mount applications. It utilizes InGaN on Sapphire technology for reliable light emission.



The LED has a dominant wavelength of 525nm and a peak wavelength of 515nm, providing a clear green light. It offers a typical luminous intensity of 600mcd at 20mA and a wide viewing angle of 120°. The forward voltage is typically 3.3V.



Packaged in a 2-PLCC surface mount package, this LED is suitable for automated SMT assembly and soldering processes. It operates within a temperature range of -40°C to +85°C and is supplied on tape and reel with 1500 pieces per reel.



Key electrical characteristics include a typical forward current of 30mA and a peak forward current of 150mA. The reverse voltage is rated at 5V, and the capacitance is 45pF at 0V and 1MHz.

AA3528AZGC Quick Information

Product Type: LED
Canonical Name: Kingbright AA3528AZGC Green LED
Subcategory: Discrete LED

AA3528AZGC Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): Level 1 Unlimited
REACH Status: REACH Unaffected

AA3528AZGC Estimated Pricing

Qty Low High
1+ $0.99 $0.99

Estimated market price range - modelled values for guidance only, not live distributor offers.

AA3528AZGC Features

  • Green LED with clear, colorless lens.
  • Surface mount 2-PLCC package.
  • 525nm dominant wavelength.
  • 120° viewing angle.
  • 1500 pieces per reel.

AA3528AZGC Applications

  • Suitable for LED backlighting applications.
  • Ideal for indicator lights in electronic devices.
  • Used in display and signage lighting.
  • Applicable in low-voltage illumination projects.

AA3528AZGC FAQs

7 frequently asked questions generated from this part’s specifications.
What is the dominant wavelength of the AA3528AZGC LED?

The dominant wavelength is 525nm.

What is the typical forward voltage for the AA3528AZGC LED?

The typical forward voltage is 3.3V.

What is the viewing angle of the AA3528AZGC LED?

The viewing angle is 120°.

What is the operating temperature range for this LED?

The operating temperature range is -40°C to +85°C.

What is the package type for the AA3528AZGC LED?

The package type is 2-PLCC.

Is the AA3528AZGC LED RoHS compliant?

Yes, it is RoHS3 Compliant.

What is the Moisture Sensitivity Level (MSL) for this component?

The Moisture Sensitivity Level is Level 1 Unlimited.
