The Delta Electronics AA30T051212C is an encapsulated, compact AC-DC power module from the AA30S/D/T series, delivering 30W of power.
This module features a universal input voltage range of 85-264 VAC and provides triple outputs: +5VDC, +12VDC, and -12VDC. It is designed for applications requiring ITE (Commercial) compliance and offers a typical efficiency of 76%. The power module includes over-load and over-voltage protection.
With a chassis mount type, this AC-DC converter is suitable for industrial electronic equipment. It operates within a temperature range of -25°C to 70°C and provides 3000VAC isolation. The dimensions are 112.0mm x 63.8mm x 25.6mm.
Key certifications include CE marking, and it is RoHS3 compliant. The product comes with a 3-year warranty.
85-264 VAC (47-440 Hz), also DC input capable.
+5VDC at 3000mA, +12VDC at 600mA, -12VDC at -600mA.
30W.
-25°C to 70°C.
3000 VAC.
Chassis mount.
3.
