| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Frequency | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Package / Case | |
| Power (Watts) | |
| SVHC Present | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The Delta Electronics AA30S2400A is a 30W encapsulated AC-DC power module designed for commercial and industrial applications. It provides a single 24VDC output and accepts a universal input voltage range of 85-264 VAC.
Key electrical specifications include a maximum output current of 1.25A and an efficiency of 80% typical. The module offers 3000 VAC isolation and meets Protection Class II requirements. It is certified to UL/IEC/EN 60950-1 standards.
This power module is designed for through-hole mounting and comes in a 7-DIP module package with 5 leads. It operates within a temperature range of -25°C to 70°C with derating. The compact dimensions are 89.9mm in length, 63.5mm in width, and 21.7mm in height.
Additional features include overload and overvoltage protection. The product is RoHS3 compliant and lead-free, suitable for various electronic equipment designs.
The output voltage is 24 VDC.
The maximum output current is 1.25A.
The input voltage range is 85-264 VAC.
The typical efficiency is 80%.
The dimensions are 89.9mm in length, 63.5mm in width, and 21.7mm in height.
The operating temperature range is -25°C to 70°C (With Derating).
The RoHS status is RoHS3 Compliant.
