| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Package / Case | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
This Delta Electronics AA15S4800A is an enclosed AC/DC converter with a power output of 15W. It operates with a wide input voltage range of 85 to 264 VAC and provides a single output current of 310mA.
The converter is designed for ITE (Commercial) applications and features universal input. It has an efficiency of 79% and is compliant with standards such as CE, cUL, and UL, including 60950-1.
With a compact size of 74.0mm x 54.0mm x 19.5mm, it is suitable for through-hole mounting. The operating temperature range is -25°C to 70°C with derating. The RoHS status is RoHS3 Compliant, and the Moisture Sensitivity Level (MSL) is 1 Unlimited.
85 to 264 VAC.
7-DIP Module with 4 leads.
-25°C to 70°C with derating.
48V DC.
15W.
310mA.
Through hole.
