The Delta Electronics AA10S Series is an ultra-compact, isolated, fully encapsulated 10W AC/DC power module suitable for PCB mounting. This module provides a single 15V output at 667mA, with a power rating of 10W. It features a universal input voltage range of 85-264 VAC and an input frequency range of 47-440 Hz.
Key features include over-load and over-voltage protection, 3kVAC isolation, and compliance with EMI standards EN55022 Class B and EMS to EN61000-4. The module is certified to UL/IEC/EN 60950-1 and CE Marked, meeting Protection Class II requirements. It operates within a temperature range of -25°C to 70°C with derating.
Designed for applications in commercial and industrial electronic equipment, the AA10S1500A offers high reliability and excellent electrical and thermal performance. Its compact dimensions (52.3mm x 27.2mm x 23.5mm) and through-hole mounting make it suitable for space-constrained designs. The module also includes short circuit protection with hiccup mode and auto-recovery.
This power module is lead-free and RoHS compliant. It is ideal for integration into various electronic systems requiring a stable and reliable AC to DC power conversion.
The output voltage is 15 VDC.
The maximum output current is 667mA.
The power rating is 10 W.
The input voltage range is 85-264 VAC.
The typical efficiency at 115VAC and maximum load is 75%.
The operating temperature range is -25°C to 70°C (With Derating).
The package type is 4-DIP Module.
