| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Cable Length | |
| Cord Length | |
| Current | |
| Dimensions | |
| Efficiency | |
| Form | |
| Height | |
| Input Connector | |
| Input Type | |
| Insulation Resistance | |
| Lead Style | |
| Length | |
| No Load Power Consumption | |
| Operating Temperature | |
| Output Connector | |
| Output Power | |
| Polarization | |
| Power (Watts) | |
| Region Utilized | |
| Standard Number | |
| Standards | |
| Voltage | |
| Weight | |
| Width |
The Phihong USA AA10K-050A-R is a 10W AC/DC wall mount adapter designed for reliable power delivery. It offers a stable 5.0V DC output with a maximum current of 2.0A, regulated to within ±1%. The adapter operates within a wide AC input voltage range of 90 to 264VAC and a frequency of 47 to 63Hz.
Key features include a fixed blade AC input suitable for the United Kingdom, and a 1.50m (59") DC cable with a 2.1mm x 5.5mm x 9.5mm barrel plug connector. The adapter meets various safety and EMC standards, including IEC 62368-1 and EN 55032/CISPR 32 Class B for EMI emissions. Its compact dimensions are 71.2mm x 49.1mm x 77.9mm, weighing 75.5g.
This adapter is suitable for applications such as MPEG players, personal electronics, PDAs, and digital cameras. It complies with Ecodesign/ErP Lot 7 (EU) 2019/1782 and CoC Version 5 Tier 2 standards, ensuring energy efficiency. The operating temperature range is from 0°C to +40°C.
5.0V DC.
2.0A maximum.
90 to 264VAC.
0°C to +40°C.
Yes.
Over-voltage protection (9.0V max), over-current protection (2.2A max), and short circuit protection.
Level VI.
