| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Current | |
| Output Voltage | |
| Package / Case | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The Delta Electronics AA07S1200A is an enclosed AC/DC power supply module designed for PCB mounting. It offers a single 12V DC output with a maximum current of 583mA, providing 7W of power.
This converter features a universal input voltage range of 85-264 VAC and an efficiency of 78% at 115VAC, 60Hz under maximum load. Key electrical specifications include line regulation of ±0.5% and load regulation of ±0.5%. It also provides 3000 VACrms of isolation between input and output.
The unit is designed for Through Hole mounting and comes in a 4-DIP Module package. Its dimensions are 50.8mm in length, 25.4mm in width, and 19.5mm in height. The operating temperature range is -25°C to 70°C with derating.
Compliance and safety approvals include CE and UL, with a standard number of 60950-1. The RoHS status is RoHS3 Compliant, and the Moisture Sensitivity Level (MSL) is 1 Unlimited.
The output voltage is 12 VDC.
The maximum output current is 583mA.
The input voltage range is 85-264 VAC.
The power rating is 7 W.
The typical efficiency is 78% at 115VAC, 60Hz under maximum load.
The dimensions are 50.8mm in length, 25.4mm in width, and 19.5mm in height.
The operating temperature range is -25°C to 70°C (With Derating).
