| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Input Frequency | |
| Isolation | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Package / Case | |
| Power (Watts) | |
| Standard Number | |
| Type | |
| Voltage | |
| Width |
The Delta Electronics AA04S2400A is a 4W AC/DC power module designed for PCB mounting. It operates with a universal input voltage range of 85-264 VAC and 47-440 Hz, providing a stable 24VDC output at 167mA.
Key features include 3kVAC isolation, Over Load and Over Voltage Protection, and EMI compliance to EN55032 Class B. The module is certified to UL/IEC/EN 60950-1 standards and carries CE marking, making it suitable for commercial and industrial electronic equipment applications.
With a compact package dimension of 27.0x36.5x17.1mm, it offers a space-efficient solution. The operating temperature range is -25°C to 60°C with derating. This series is lead-free and RoHS compliant, backed by a 3-year product warranty.
The nominal output voltage for the AA04S2400A is 24 VDC.
The input voltage range is 85-264 VAC or 120-370 VDC.
This AC/DC converter has a power rating of 4 Watts.
The operating temperature range is -25°C to 60°C with derating.
The package dimensions are 36.5mm x 27.0mm x 17.1mm.
Yes, it meets EN55032 Class B EMI standards.
It is certified to UL/IEC/EN 60950-1 standards and is CE Marked.
