Mfr Part #:

A8296SESTR-T

The Allegro Microsystems A8296SESTR-T is a single LNB supply and control voltage regulator designed for satellite receivers. It offers adjustable current limits and programmable output voltage levels.

✓ Total Stock: 8,888 pcs

$ Price Range: $0.75

A8296SESTR-T Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Smaxon Electronics ✓ Non-Authorised Inventory information	8,888 pcs On Request	8888 pcs	On Request	1	On Request	On Request	13+14+	On Request	On Request

A8296SESTR-T Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	Special Purpose Regulators
Manufacturer Name	Allegro Microsystems
Applications	Converter, Analog and Digital Satellite Receivers
Interface	I2C-compatible
Mounting Type	Surface Mount
Number of Outputs	1
Operating Temperature	-20 °C / 85 °C
Supplier Device Package	16-QFN/MLP (3x3)

View Similar Products (0)

A8296SESTR-T Description

Short technical summary and product information.

The Allegro Microsystems A8296SESTR-T is a monolithic linear and switching voltage regulator designed for analog and digital satellite receivers. It provides power and interface signals to an LNB down converter via coaxial cable, requiring few external components.

Key features include integrated boost MOSFET, current sensing, and compensation. It supplies up to 500 mA continuously with an adjustable LNB output current limit ranging from 300 to 500 mA. The device supports 8 programmable LNB output voltage levels and includes an LNB overcurrent limiter with a shutdown timer. A tracking boost converter minimizes power dissipation, and LNB transition times are configurable.

For DiSEqC communications, a tone control pin gates an internally-generated 22 kHz tone. The regulator includes extensive protection features such as UVLO, OCP, TSD, and CPOK. It communicates via a 2-wire bidirectional serial interface compatible with the I2C standard, operating up to 400 kHz.

The A8296SESTR-T is supplied in a 16-lead QFN/MLP (3x3) package, surface mounted, and operates within a temperature range of -20°C to 85°C.

A8296SESTR-T Quick Information

Product Type: Voltage Regulator

Canonical Name: Single LNB Supply and Control Voltage Regulator

Subcategory: Special Purpose Regulators

A8296SESTR-T Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

A8296SESTR-T Estimated Pricing

Qty	Low	High
1+	$0.75	$0.75

Estimated market price range - modelled values for guidance only, not live distributor offers.

A8296SESTR-T Features

Supplies up to 500 mA continuously.
Adjustable LNB output current limit.
8 programmable LNB output voltage levels.
Built-in 22 kHz tone oscillator.
2-wire I2C-compatible interface.

A8296SESTR-T Applications

Analog satellite receivers.
Digital satellite receivers.
LNB down converter power.
DiSEqC tone encoding.

A8296SESTR-T FAQs

7 frequently asked questions generated from this part’s specifications.

What is the package type of the A8296SESTR-T?

The A8296SESTR-T is available in a 16-WFQFN Exposed Pad package, also specified as 16-QFN/MLP (3x3 mm).

What is the operating temperature range?

The operating temperature range is -20°C to 85°C.

What is the adjustable output current range?

The LNB output current limit is adjustable from 300 mA to 500 mA.

How many output voltage levels are programmable?

There are 8 programmable LNB output voltage (DAC) levels.

What interface does the A8296SESTR-T use?

It uses a 2-wire I2C-compatible interface operating up to 400 kHz.

Does it include a tone oscillator?

Yes, it has a built-in 22 kHz tone oscillator.

How many outputs does the A8296SESTR-T have?

It has a single output.
