A6276EA The Allegro MicroSystems A6276EA is a 16-bit serial input, constant-current latched LED driver IC designed for LED display applications. It offers up to 90 mA constant-current outputs and operates with a 4.5V to 5.5V supply voltage.
Mfr Part #:

A6276EA

Available from 1 distributors
Mfr Name: Allegro Microsystems
Allegro Microsystems
The Allegro MicroSystems A6276EA is a 16-bit serial input, constant-current latched LED driver IC designed for LED display applications. It offers up to 90 mA constant-current outputs and operates with a 4.5V to 5.5V supply voltage.
✓ Total Stock: 5,245 pcs
$ Price Range: $0.17

A6276EA Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Components Technology Group, Inc. ✓
Non-Authorised Inventory information
5,245 pcs
On Request
5245 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

A6276EA Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Current
Frequency
Internal Switch(s)
Lead Spacing
Lead Style
Mounting Type
Number of Outputs
Operating Temperature
Output Voltage
Storage Temperature
Supplier Device Package
Topology
Type
Voltage
View Similar Products (0)

A6276EA Description

Short technical summary and product information.

The Allegro MicroSystems A6276EA is a BiCMOS device designed for LED-display applications, featuring a 16-bit CMOS shift register, data latches, and 16 NPN constant-current sink drivers. It allows direct interfacing with microprocessor-based systems with a typical serial data input rate of up to 20 MHz when using a 5V logic supply.



The device provides up to 90 mA constant-current outputs, with the specific current determined by a user-selected resistor. It includes undervoltage lockout and a low-power CMOS logic. A CMOS serial data output enables cascaded connections for applications requiring additional drive lines. All output drivers can be disabled with an ENABLE input high for inter-digit blanking.



The A6276EA is available in a 24-pin DIP (Dual In-line Package) through-hole package, measuring 0.300 inches (7.62mm) wide. It operates within an ambient temperature range of -40°C to 85°C. This LED driver is a functional replacement for the TB62706BN/BF.



All packages are lead (Pb) free, with 100% matte tin leadframe plating.

A6276EA Quick Information

Product Type: LED Driver IC
Canonical Name: A6276EA 16-Bit Serial Input, Constant-Current Latched LED Driver
Subcategory: Linear

A6276EA Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

A6276EA Estimated Pricing

Qty Low High
1+ $0.17 $0.17

Estimated market price range - modelled values for guidance only, not live distributor offers.

A6276EA Features

  • 16 constant-current sink drivers.
  • Up to 90 mA constant-current outputs.
  • Operates with 4.5V to 5.5V supply voltage.
  • High data input rate up to 20 MHz.
  • Available in 24-DIP through-hole package.

A6276EA Applications

  • Designed for LED-display applications.
  • Suitable for microprocessor-based systems.
  • Enables cascaded connections for more drivers.
  • Supports inter-digit blanking functionality.

A6276EA FAQs

5 frequently asked questions generated from this part’s specifications.
What is the operating voltage range of the A6276EA?

The recommended supply voltage range is 4.5V to 5.5V per the manufacturer page; the datasheet specifies a maximum of 7V.

What package does the A6276EA come in?

The A6276EA is available in a 24-DIP (0.300", 7.62mm) through-hole package.

What is the operating temperature range of the A6276EA?

The operating temperature range is -40°C to 85°C according to the manufacturer page, and -20°C to 85°C according to the datasheet.

What is the typical output current of the A6276EA?

The typical output current is 75.5 mA, with a maximum rating of 90 mA.

What is the maximum data input rate?

The typical data input rate is 20 MHz with a 5V logic supply.
