A019 The LEDdynamics Inc. A019 is a dimming switch designed for use with LUXdrive A009 and other compatible LUXdrive products. It supports 0-10V dimming input.
Mfr Part #:

A019

Mfr Name: LEDdynamics Inc.
LEDdynamics Inc.
The LEDdynamics Inc. A019 is a dimming switch designed for use with LUXdrive A009 and other compatible LUXdrive products. It supports 0-10V dimming input.
Stock on Request

A019 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Accessory Type
For Use With
Input Voltage
Operating Temperature
Power Consumption
SVHC Present
Viewing Angle
View Similar Products (0)

A019 Description

Short technical summary and product information.

The LEDdynamics Inc. A019 is a dimming switch accessory, specifically designed for integration with LUXdrive A009 BuckBlock, A011 FlexBlocks, and 3021/3023 BuckPuck systems. This accessory facilitates dimming control for compatible LED lighting setups.



It features a 0-10V dimming input, allowing for precise control over light intensity when used with appropriate dimming controls. The switch is designed to operate within an input voltage range of 12-25V DC, with an absolute maximum rating of 28V DC. The operating temperature range is -40°C to +50°C, making it suitable for a variety of environmental conditions.



This dimming switch is part of the LUXdrive accessory line, enhancing the functionality and control of their LED driver systems. Its primary function is to enable variable light output, contributing to energy efficiency and customizable lighting environments.

A019 Quick Information

Product Type: Dimming Switch
Canonical Name: Dimming Switch
Subcategory: Accessories

A019 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

A019 Features

  • Supports 0-10V analog dimming input.
  • Operates from 12-25V DC supply.
  • Low 0.15-inch profile height.
  • Wide 120° viewing angle.
  • End-to-end connectable up to 10 feet.

A019 Applications

  • Used in LED strip accent and task lighting.
  • Ideal for architectural lighting installations.
  • Controllable with standard 0-10V dimmers.
  • Suitable for commercial and residential applications.

A019 FAQs

6 frequently asked questions generated from this part’s specifications.
What is the input voltage range for the A019?

12-25 V DC, with an absolute maximum of 28 V DC.

What is the operating temperature range?

-40 to +50 °C.

What type of dimming does the A019 support?

0-10V analog dimming.

How much power does the A019 consume?

5 W at 20°C.

Can the connected strip be cut to custom lengths?

Yes, it can be cut at 4" or 8" intervals.

What is the maximum connectable length?

Up to 10 feet end-to-end.
