| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3 pcs
|
3 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Air Flow | |
| Approval Agency | |
| Bearing Type | |
| Fan Type | |
| Features | |
| Ingress Protection | |
| Lead Style | |
| Noise | |
| Operating Temperature | |
| Power (Watts) | |
| RPM | |
| SVHC Present | |
| Static Pressure | |
| Tape & Reel | |
| Termination | |
| Voltage | |
| Weight | |
| Width |
The Sanyo Denki 9WV0848P1H001 is a high-performance tubeaxial fan designed for demanding cooling applications. Operating at 48VDC and consuming 36W, it delivers 131 CFM of airflow with a static pressure of 1.770 in H2O at 9700 RPM.
This fan features a ball bearing system for reliable long-life operation and includes PWM control and a tachometer output for precise speed monitoring. Its IP68 rating ensures dust-tight and waterproof performance, making it suitable for harsh environments. The operating temperature range is -20°C to 70°C.
With a compact 80mm x 80mm x 38mm frame and 4-wire lead termination, the 9WV0848P1H001 integrates easily into various electronic enclosures. It is approved by CSA, TUV, and UL for safety compliance.
| Qty | Low | High |
|---|---|---|
| 1+ | $89.25 | $89.25 |
| 10+ | $74.06 | $74.06 |
| 25+ | $69.06 | $69.06 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
48VDC.
-20 to 70°C (-4 to 158°F).
Listed as RoHS3 Compliant, but this status is unverified.
131.0 CFM (3.67 m³/min).
1.770 in H2O (440.9 Pa).
63.0 dB(A).
IP68 - Dust Tight, Waterproof.
