| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
4,484 pcs
|
4484 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| ESR (Equivalent Series Resistance) | |
| Frequency | |
| Frequency Tolerance | |
| Height | |
| Lead Style | |
| Length | |
| Load Capacitance | |
| Mounting Type | |
| Operating Mode | |
| Operating Temperature | |
| Package / Case | |
| Tape & Reel | |
| Type | |
| Width |
The TXC 9H03200030 is a 32.768 kHz tuning fork crystal designed for surface mount applications. It operates in fundamental mode with a load capacitance of 12.5pF and a frequency tolerance of ±20ppm, providing reliable timing for low-power circuits.
The crystal features a maximum equivalent series resistance (ESR) of 90kΩ and operates over a temperature range of -40°C to 85°C. Its compact 2-SMD, no-lead package measures 1.60mm x 1.00mm with a height of 0.50mm, making it suitable for space-constrained PCB designs.
This component is commonly used in real-time clock (RTC) circuits, microcontroller timing, and other applications requiring a stable 32.768 kHz reference frequency. The surface mount package supports automated assembly processes.
| Qty | Low | High |
|---|---|---|
| 5,000+ | $0.59 | $0.59 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The crystal operates at 32.768 kHz in fundamental mode.
The load capacitance is 12.5pF.
The frequency tolerance is ±20ppm.
The operating temperature range is -40°C to 85°C.
It comes in a 2-SMD, no-lead surface mount package measuring 1.60mm x 1.00mm with a height of 0.50mm.
The maximum ESR is 90kΩ.
The database indicates RoHS3 compliance, but this is unverified and should be confirmed with the manufacturer.
