| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
100 pcs
|
100 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AWM Compliance | |
| Bend Radius (Stationary, Installation) | |
| Bulk Cable Weight | |
| CSA Compliance | |
| Cable Diameter (Nominal) | |
| Cable Type | |
| Conductor DC Resistance (Nominal) | |
| Conductor Material | |
| Conductor Strand | |
| Conductor Stranding | |
| Current Rating (Single conductor, free air @ 30°C) | |
| Flammability Rating | |
| Jacket (Insulation) Diameter | |
| Jacket (Insulation) Material | |
| Jacket (Insulation) Thickness | |
| Jacket Color | |
| Length | |
| Max Pull Tension | |
| Operating Temperature | |
| Operating Temperature Range | |
| Packaging Type | |
| Prop 65 | |
| Ratings | |
| Reel Length | |
| UL Style | |
| Voltage | |
| Voltage Rating | |
| Wire Gauge |
The Belden 9921 003100 is a single conductor hook-up wire designed for internal wiring of electronic equipment and appliances. It features a 22 AWG (7x30) stranded tinned copper conductor for flexibility and corrosion resistance, insulated with a PVC jacket that provides a nominal thickness of 0.017 in (0.43 mm) and an overall diameter of 0.062 in (1.6 mm). The wire is rated for 300 V RMS and has an operating temperature range of -20°C to 105°C. It is UL Style 1007/1569 and AWM 1007/1569 compliant, with VW-1 flammability rating. The cable is delivered on a reel with a length of 100 ft (30.5 m). Applications include inter-connection circuits and internal wiring of computers, electronic equipment, and appliances. The conductor DC resistance is 18.1 Ohm/1000ft, and the maximum current rating is 11 A per single conductor in free air at 30°C. The minimum bend radius for stationary installation is 16 mm, and the maximum pull tension is 9 lbs (4.1 kg). This wire is RoHS compliant and meets CA Prop 65 requirements.
| Qty | Low | High |
|---|---|---|
| 100+ | $1.29 | $1.29 |
| 200+ | $1.23 | $1.23 |
| 300+ | $1.19 | $1.19 |
| 500+ | $1.15 | $1.15 |
| 700+ | $1.12 | $1.12 |
| 1,000+ | $1.09 | $1.09 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
300 V RMS.
-20°C to 105°C.
Yes, RoHS3 compliant (EU RoHS 2).
22 AWG.
Tinned copper.
100 ft (30.5 m).
11 A (single conductor in free air at 30°C).
