| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
321 pcs
|
321 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Halogen Free | |
| Industrial Grade | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The Amphenol ICC 98424-G52-26ALF is a 26-position, 2.00mm pitch shrouded header designed for board-to-board or cable applications. It features a surface mount termination with solder contacts and a latch holder for secure mating.
This connector has a 4-wall shrouded design with a cream thermoplastic insulator rated UL94 V-0. The male square pins are made of copper alloy with a tin contact finish (30.0µin). The insulation height is 6.20mm and the contact length is 4.00mm.
Electrical ratings are 2A (AC/DC) and 200V (AC/DC). The part includes keying slot and pick-and-place features for automated assembly. It is RoHS3 compliant and has an MSL of 1 (unlimited).
It has 26 positions, all loaded, arranged in 2 rows.
The pitch is 2.00mm (0.079 inches).
The current rating is 2A (AC/DC).
The voltage rating is 200V (AC/DC).
It is a surface mount (SMD) component with solder termination.
The contact finish is tin with a thickness of 30.0µin (0.76µm).
Yes, it is listed as RoHS3 compliant.
