98414-G06-10LF This is a 10-position, 2-row, 2.00mm pitch shrouded header from Amphenol ICC. It features a through hole mount, male pins with tin finish, and a latch holder fastening.
Mfr Part #:

98414-G06-10LF

Available from 4 distributors
Mfr Name: Amphenol ICC
Amphenol ICC
This is a 10-position, 2-row, 2.00mm pitch shrouded header from Amphenol ICC. It features a through hole mount, male pins with tin finish, and a latch holder fastening.
✓ Total Stock: 1,326 pcs

98414-G06-10LF Available from 4 distributors

✓ Authorised
✓ Non-Authorised
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

98414-G06-10LF Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Length
Contact Material
Contact Shape
Contact Type
Current Rating
Current Rating (Amps)
Fastening Type
Features
Halogen Free
Insulation Color
Insulation Height
Insulation Material
Lead Spacing
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Pitch
Row Spacing
SVHC Present
Shrouding
Style
Termination
Voltage Rating
View Similar Products (0)

98414-G06-10LF Description

Short technical summary and product information.

The Amphenol ICC 98414-G06-10LF is a 10-position, 2-row header with a 2.00mm pitch and row spacing. It features a shrouded 4-wall design with a latch holder for secure mating and a keying slot for polarization. The header is rated for 2A AC/DC at 200V AC/DC maximum. Contacts are made of copper alloy with a 0.76µm tin finish, and the insulation is thermoplastic with a UL94 V-0 flammability rating. The insulation height is 5.90mm and the color is cream. This through hole mount component is suitable for board-to-board or cable applications, providing reliable solder connections and mechanical stability. The latch holder ensures retention, making it ideal for applications where vibration resistance is needed. The keying slot prevents mismating, enhancing system reliability.

98414-G06-10LF Quick Information

Product Type: Shrouded Header
Canonical Name: Amphenol ICC 98414-G06-10LF - 10 Position 2mm Pitch Through Hole Header
Subcategory: Shrouded Header

98414-G06-10LF Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: No

98414-G06-10LF Features

  • 10 positions in 2 rows with 2.00mm pitch.
  • Shrouded 4-wall design with latch holder.
  • Rated for 2A AC/DC at 200V.
  • Through hole mounting for reliable solder joints.
  • UL94 V-0 flammability rated thermoplastic insulation.

98414-G06-10LF Applications

  • Used in board-to-board connections requiring secure mating.
  • Ideal for cable-to-board applications with latch holder.
  • Suitable for industrial control and automation systems.
  • Applicable in consumer electronics and data communication.

98414-G06-10LF FAQs

7 frequently asked questions generated from this part’s specifications.
What is the number of positions on this header?

The header has 10 positions.

What is the pitch of this header?

The pitch is 2.00mm.

What is the current rating of this header?

The current rating is 2A maximum (AC/DC).

What is the voltage rating of this header?

The voltage rating is 200V maximum (AC/DC).

What is the mounting type of this header?

The mounting type is through hole.

How many rows does this header have?

The header has 2 rows.

What is the shrouding type of this header?

The header is shrouded with a 4-wall design.
