| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Style | |
| Connector Type | |
| Contact Form | |
| Contact Material | |
| Contact Type | |
| Current Rating | |
| Dielectric Material | |
| Flange Feature | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Operating Temperature | |
| Shell Material | |
| Shell Size, Connector Layout | |
| Termination |
The HARTING 9654216701 is a D-Sub connector assembly designed for signal applications. It features a plug with male pins and a total of 37 positions arranged in 2 rows. The connector utilizes through-hole mounting and has a solder termination style.
With a current rating of 6.5A, this connector is built to withstand operating temperatures from -55°C to 125°C. The dielectric material is Polybutylene Terephthalate (PBT), Polyester, Glass Filled, and the shell is made of steel. The connector style is D-Sub, with a shell size and layout of 4 (DC, C). It also includes grounding indents for enhanced functionality.
This component has a material flammability rating of UL94 V-0, indicating its resistance to fire. The contact material is a copper alloy, and the contact form is stamped. The standard package quantity is 50 units.
The HARTING 9654216701 is RoHS3 Compliant, REACH Unaffected, and has a Moisture Sensitivity Level (MSL) of 1 Unlimited.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.22 | $0.22 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The current rating is 6.5A.
The connector has 37 positions.
The operating temperature range is -55°C to 125°C.
It uses through-hole mounting.
The termination style is solder.
The material flammability rating is UL94 V-0.
The standard package quantity is 50 parts.
