| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1 pcs
|
1 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Insulation Resistance | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Overall Contact Length | |
| Pitch | |
| Processing Temperature | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination | |
| Termination Style | |
| Transition Resistance | |
| Withstanding Voltage |
The 3M 951240-8622-AR is a 40-position, 2-row, through hole pin strip header part of the 951 Series. It has unshrouded male pins with a square contact shape and a 2.00mm pitch. The contacts are made of copper alloy with a flash gold plating on the wiping area and matte tin on the solder tail area. The insulator is a high temperature thermoplastic (UL94 V-0) in black color.
The header is rated for 1A current and can operate over a temperature range of -55°C to 125°C. It has an insulation resistance of >5x10⁹ Ohm at 100VDC and a withstanding voltage of 1000VDC. The transition resistance is ≤20mOhm. The component is RoHS compliant and has an MSL of 1 (unlimited).
This header is designed for board-to-board applications and is stackable. It mates with both boardmount and wiremount products. The processing temperature is up to 260°C per J-STD-020C profile.
This header has 40 positions in 2 rows.
The pitch is 2.00mm.
The current rating is 1A.
The mounting type is through hole with solder termination.
Yes, it is RoHS compliant per RIA E1 & C1.
The operating temperature range is -55°C to 125°C.
The insulator material has a flammability rating of UL94 V-0.
