| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2 pcs
|
2 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current Rating | |
| DC Resistance (DCR) | |
| Diameter | |
| Height | |
| Inductance | |
| Mounting Type | |
| Operating Temperature | |
| Q @ Freq | |
| Self Resonant Frequency | |
| Shielding | |
| Tape & Reel | |
| Tolerance |
The 9405-32 is a fixed shielded inductor from API Delevan Inc., part of the 9405 series. It offers an inductance of 47µH with ±10% tolerance and a current rating of 242mA. The DC resistance is 3.7 Ohm maximum. This inductor features a ferrite core and is fully shielded, providing effective electromagnetic interference suppression.
Electrical characteristics include a Q factor of 76 at 2.5MHz, a self-resonant frequency of 8MHz, and a test frequency of 2.5MHz. The operating temperature range spans -55°C to 125°C, suitable for demanding environments.
The component is packaged in a through hole radial case with a diameter of 9.65mm and a seated height of 12.70mm. It is supplied in bulk packaging.
| Qty | Low | High |
|---|---|---|
| 100+ | $73.84 | $73.84 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The inductance is 47µH with ±10% tolerance.
The current rating is 242mA.
The maximum DC resistance is 3.7 Ohm.
The operating temperature range is -55°C to 125°C.
Yes, it is shielded.
The package is a through hole radial case.
