| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
375 pcs
|
375 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Insulation Resistance | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Overall Contact Length | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination | |
| Withstanding Voltage |
The 3M 929665-01-08-I is a 16 position, dual row unshrouded pin strip header from the 929 Series. It features a 2.54mm (0.100") pitch and row spacing, making it suitable for board-to-board stacking applications. The header uses square male pins made of copper alloy with a gold contact finish of 0.25µm over a 1.27µm nickel underplating.
The insulator is black glass filled PBT (Polybutylene Terephthalate) with a UL94 V-0 flammability rating. The component is rated for a current of 2.5A and an operating temperature range of -40°C to +105°C. It has a withstanding voltage of 1500 Vrms at sea level and an insulation resistance greater than 5 × 10^9 Ω at 500 VDC.
This header is designed for through hole mounting with solder termination and has a push-pull fastening type. The overall contact length is 11.30mm (0.445") with a mating length of 5.97mm (0.235"). The part is MSL Level 1 per J-STD-020C and is RoHS3 and REACH compliant as per database records.
| Qty | Low | High |
|---|---|---|
| 1+ | $3.75 | $3.75 |
| 10+ | $3.41 | $3.41 |
| 100+ | $3.00 | $3.00 |
| 500+ | $2.55 | $2.55 |
| 1,000+ | $2.18 | $2.18 |
| 5,000+ | $1.95 | $1.95 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch is 2.54mm (0.100").
It has 16 positions arranged in 2 rows.
The current rating is 2.5A.
Through hole with solder termination.
-40°C to +105°C.
Gold, 0.25µm thick.
