| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
58 pcs
|
58 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Length - Mating | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Insulation Resistance | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Shrouding | |
| Style | |
| Temperature Rating - Process | |
| Termination | |
| UL | |
| Withstanding Voltage |
The 929500-01-36-RK is a 36 position single row right angle through-hole male pin header from 3M's 929 Series. This unshrouded header features a 2.54mm pitch and square contacts with tin plating over a 1.27μm nickel underplating. The insulator is molded from black Polycyclohexylenedimethylene Terephthalate (PCT) with a UL94 V-0 flammability rating. Designed for board-to-board interconnects, the header provides a push-pull mating interface with a 7.49mm mating contact length. Electrical ratings include a 2.5A current capacity and a withstanding voltage of 1500 VRMS at sea level. The component is rated for operating temperatures from -40 to +105°C and supports a process rating of 260°C per J-STD-020C for PCT insulators, making it suitable for wave soldering. The right angle orientation enables perpendicular connections between PCBs, saving vertical space.
| Qty | Low | High |
|---|---|---|
| 1+ | $3.55 | $3.55 |
| 10+ | $3.02 | $3.02 |
| 300+ | $2.37 | $2.37 |
| 600+ | $2.26 | $2.26 |
| 1,200+ | $2.15 | $2.15 |
| 5,100+ | $1.94 | $1.94 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
36 positions in a single row.
2.54mm (0.100 inches).
2.5A per pin.
Through hole, right angle with solder termination.
-40°C to +105°C.
RoHS compliance is listed as unverified with low confidence; treat as low-confidence.
Polycyclohexylenedimethylene Terephthalate (PCT) with UL94 V-0 rating.
