| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
10,470 pcs
|
10470 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| China RoHS | |
| Circuit Application | |
| Color | |
| Connector Length | |
| Connector Type | |
| Contact Current Rating (Max) | |
| Contact Termination | |
| Contact Type | |
| ELV | |
| Halogen Free | |
| Housing Entry Configuration | |
| Housing Material | |
| Lead Spacing | |
| Mating Retention | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Operating Temperature | |
| Operating Voltage | |
| Packaging Method | |
| Packaging Quantity | |
| Pitch | |
| Row-to-Row Spacing | |
| Strain Relief | |
| connector_height |
The TE Connectivity 926475-6 is a wire-to-board receptacle housing from the AMPMODU IV/V series. It accommodates 16 female socket contacts in a single row with 2.54mm pitch, making it suitable for compact signal applications. The housing is designed for free-hanging cable mounting and uses crimp termination for reliable wire attachment. It is rated for 3A per contact and 250VAC operating voltage, with an operating temperature range of -65°C to 105°C. The black PBT GF housing features a strain relief and both ends closed configuration, ensuring secure mating. It is supplied in bags of 1000 pieces. Compliance includes RoHS, REACH, ELV, and China RoHS, but it is not halogen-free.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.46 | $1.46 |
| 10+ | $1.24 | $1.24 |
| 25+ | $1.16 | $1.16 |
| 50+ | $1.10 | $1.10 |
| 100+ | $1.05 | $1.05 |
| 250+ | $0.99 | $0.99 |
| 500+ | $0.94 | $0.94 |
| 1,000+ | $0.89 | $0.89 |
| 3,000+ | $0.83 | $0.83 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The connector has 16 positions arranged in a single row.
The pitch is 2.54 mm (0.100 inches).
The maximum current rating is 3 A per contact.
The operating voltage is 250 VAC.
It is a cable mount (free-hanging) connector.
The operating temperature range is -65°C to 105°C.
Yes, it is EU RoHS 2011/65/EU compliant.
