| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
477 pcs
|
477 pcs | On Request | 1 | On Request | On Request | NDC | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Automotive Grade | |
| Current | |
| Current Rating (Amps) | |
| DC Resistance (DCR) | |
| Dielectric Strength | |
| Frequency | |
| Inductance | |
| Material | |
| Mounting Type | |
| Operating Temperature | |
| Q @ Freq | |
| Shielding | |
| Standard Package Quantity | |
| Storage Temperature Range | |
| Tape & Reel | |
| Tape & Reel Option | |
| Temperature Rise | |
| Terminal Coating | |
| Tolerance | |
| Type |
The Bourns 9250A-223-RC is a fixed inductor from the 9250A series, offering 22µH inductance with ±10% tolerance. It features a shielded molded construction with a ferrite core, ensuring low electromagnetic interference. The component is rated for a maximum DC resistance of 0.96Ω and a rated current of 290mA (temperature rise 35°C at Idc). Saturation current is 220mA typical (5% inductance drop).
This inductor provides a minimum quality factor (Q) of 45 at 2.5MHz and a minimum self-resonant frequency (SRF) of 41MHz, making it suitable for filter and output choke applications. It is packaged in an axial through-hole form factor with dimensions 0.162" diameter x 0.410" length (4.11mm x 10.41mm) and tin (Sn) terminal coating.
The operating and storage temperature range is -55°C to +125°C. Dielectric strength is 1000Vrms minimum. The part is RoHS compliant per the datasheet. Standard packaging is 500 pieces per bag, with optional tape and reel (2500 per 12-inch reel).
| Qty | Low | High |
|---|---|---|
| 1+ | $3.23 | $3.23 |
| 10+ | $2.66 | $2.66 |
| 25+ | $2.32 | $2.32 |
| 100+ | $2.16 | $2.16 |
| 250+ | $2.02 | $2.02 |
| 500+ | $1.90 | $1.90 |
| 1,000+ | $1.79 | $1.79 |
| 2,500+ | $1.66 | $1.66 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
22 µH with ±10% tolerance.
290 mA (temperature rise 35°C at Idc).
0.96 Ω maximum.
41 MHz minimum.
Axial through-hole, molded construction.
Yes, per the datasheet RoHS compliance statement.
-55°C to +125°C.
