| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
17,000 pcs
|
17000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
485 pcs
|
485 pcs | On Request | 1 | On Request | On Request | 2008 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Features | |
| Height Above Board | |
| Lead Spacing | |
| Lead Style | |
| Mated Stacking Heights | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Pitch |
The Amphenol ICC 91911-31421LF is a surface mount header connector designed for board-to-board and mezzanine applications. It features 21 positions arranged in 2 rows with a 1.00mm pitch. The connector body includes board guide and solder retention features for secure placement during assembly. The contacts are finished with gold or Gold, GXT™ plating with a thickness of 0.38µm, ensuring reliable conductivity. The mated stacking height is 6mm, and the height above board is 2.72mm. This connector is RoHS3 compliant and has a moisture sensitivity level of 1 (unlimited). It is suitable for applications requiring compact, high-density interconnections.
This connector is part of the 91911 series from Amphenol ICC, offering a reliable solution for mezzanine board stacking. The surface mount design allows for automated assembly, and the board guide aids in alignment during mating. The solder retention features help maintain solder joint integrity during thermal cycling.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.23 | $2.23 |
| 10+ | $1.89 | $1.89 |
| 25+ | $1.77 | $1.77 |
| 50+ | $1.69 | $1.69 |
| 100+ | $1.61 | $1.61 |
| 250+ | $1.51 | $1.51 |
| 500+ | $1.43 | $1.43 |
| 1,000+ | $1.37 | $1.37 |
| 1,500+ | $1.33 | $1.33 |
| 2,500+ | $1.28 | $1.28 |
| 3,500+ | $1.25 | $1.25 |
| 5,000+ | $1.22 | $1.22 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
21 positions arranged in 2 rows.
1.00mm pitch.
Surface mount.
Gold or Gold, GXT™ with 0.38µm thickness.
6mm.
Board guide and solder retention.
2.72mm.
