| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
637 pcs
|
637 pcs | On Request | 1 | On Request | On Request | 1739+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Features | |
| Height Above Board | |
| Mated Stacking Heights | |
| Mounting Type | |
| Number of Positions | |
| Number of Rows | |
| Pitch | |
| Tape & Reel |
The Amphenol ICC 91911-31409LF is a 9-position, 2-row board-to-board header designed for surface mount applications. It features a 1.00mm pitch and a mated stacking height of 6mm, making it suitable for compact mezzanine board-to-board connections.
The header includes center strip contacts with gold or GXT™ contact finish, plated to 15.0µin (0.38µm) thickness. It has a height above board of 2.72mm and includes board guide and solder retention features for reliable placement and soldering.
This component is categorized under Arrays, Edge Type, Mezzanine (Board to Board) connectors, indicating its use in parallel board stacking configurations. The surface mount termination supports automated assembly processes.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.43 | $1.43 |
| 250+ | $1.37 | $1.37 |
| 500+ | $1.31 | $1.31 |
| 1,000+ | $1.03 | $1.03 |
| 2,500+ | $1.00 | $1.00 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The 91911-31409LF has 9 positions arranged in 2 rows.
The pitch is 1.00mm (0.039 inches).
The mounting type is surface mount.
The contact finish is gold or Gold, GXT™ with a thickness of 15.0µin (0.38µm).
The mated stacking height is 6mm.
The connector includes board guide and solder retention features.
