| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
4,800 pcs
|
4800 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Automotive Grade | |
| Connector Type | |
| Contact Finish | |
| Contact Length | |
| Contact Material | |
| Contact Mating Length | |
| Contact Overall Length | |
| Contact Shape | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Flammability Rating | |
| Industrial Grade | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Spacing (Pitch) | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Overall Contact Length | |
| Pitch | |
| Shrouding | |
| Style | |
| Termination | |
| Voltage Rating |
The TE Connectivity 917783-1 is a 5 position, single row, shrouded header from the 2.5 mm Signal Double Lock (2.5 SDL) connector family. This through hole header features a 2.50mm pitch and is designed for board-to-cable/wire applications. The header is fully shrouded with a 4-wall design and includes a latch holder fastening system for secure mating. Contacts are made of copper alloy with a tin finish, and the contact mating length is 4.70mm. The insulator is natural colored polyamide (PA66) nylon 6/6, glass filled, with a UL94 V-0 flammability rating. The header is rated for 3A current and 50V voltage, with an operating temperature range of -30°C to 105°C. A board guide feature aids in alignment during assembly. This component is suitable for household appliances, gaming, vending, security systems, industrial controls, HVAC controls, and business equipment.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.60 | $0.60 |
| 10+ | $0.51 | $0.51 |
| 150+ | $0.42 | $0.42 |
| 600+ | $0.38 | $0.38 |
| 1,050+ | $0.37 | $0.37 |
| 5,100+ | $0.33 | $0.33 |
| 10,050+ | $0.31 | $0.31 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch is 2.50mm (0.098 inches).
It has 5 positions in a single row.
The current rating is 3A per line.
The voltage rating is 50V.
Through hole mounting with kinked pin solder termination.
-30°C to 105°C.
Glass filled polyamide (PA66) nylon 6/6 with UL94 V-0 rating.
