| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
13,500 pcs
|
13500 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
3 pcs
|
3 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Type | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Operating Temperature Range | |
| Pitch | |
| Row Spacing | |
| Style | |
| Tape & Reel | |
| Termination | |
| Voltage Rating |
The TE Connectivity 9-338069-0 is a 20 position dual row surface mount receptacle connector belonging to the Micro-MaTch series. It features a 2.54mm pitch and 2.54mm row spacing suitable for board-to-board or cable applications. The connector is loaded with all 20 positions using forked type contacts with tin plating.
The housing is red UL94 V-0 rated thermoplastic with an insulation height of 5.30 mm. A friction lock fastening type ensures secure mating. The part is designed for soldering termination and is pick-and-place compatible for automated assembly. Operating temperature range is -40°C to 105°C with a maximum voltage rating of 100V DC.
| Qty | Low | High |
|---|---|---|
| 1+ | $5.36 | $5.36 |
| 10+ | $4.55 | $4.55 |
| 100+ | $3.87 | $3.87 |
| 900+ | $3.32 | $3.32 |
| 1,800+ | $3.16 | $3.16 |
| 2,700+ | $3.07 | $3.07 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
Receptacle with forked contact type.
20 positions, all loaded, arranged in 2 rows with 2.54mm pitch and row spacing.
Surface mount with solder termination.
-40°C to 105°C.
100 V DC maximum.
Tin.
Compliance data not provided.
