The Marvell 88Q5050 is a second-generation secure automotive Ethernet switch designed for in-vehicle networking. This 8-port gigabit capacity switch is fully compliant with the IEEE802.3 automotive standard.
It offers 4 fixed IEEE 100BASE-T1 ports and a configurable selection of 4 additional ports, which can include IEEE 100BASE-T1, IEEE 100BASE-TX, MII/RMII/RGMII, GMII, and SGMII interfaces. The switch integrates an ARM Cortex-M7 CPU running at 250MHz, providing local and remote management capabilities.
Security is a key focus, with advanced hardware features designed to prevent hacking and denial of service attacks. These include deep packet inspection (DPI) techniques and Trusted Boot functionality. The switch also supports blacklisting and whitelisting addresses on all Ethernet ports for enhanced security. It is AEC-Q100 Grade 2 qualified and comes in a 128-pin LQFP package with dimensions of 14mm x 20mm and a pitch of 0.5mm.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The 88Q5050 offers 4 fixed IEEE 100BASE-T1 ports and a configurable selection of 4 additional ports, which can include IEEE 100BASE-T1, IEEE 100BASE-TX, MII/RMII/RGMII, GMII, and SGMII interfaces.
Key security features include deep packet inspection (DPI), Trusted Boot functionality, and support for blacklisting and whitelisting addresses on all Ethernet ports.
The 88Q5050 integrates an ARM Cortex-M7 CPU operating at 250MHz.
Yes, the 88Q5050 is AEC-Q100 Grade 2 qualified.
The 88Q5050 is supplied in a 128-pin LQFP package with dimensions of 14mm x 20mm and a pitch of 0.5mm.
