| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
4 pcs
|
4 pcs | On Request | 1 | On Request | On Request | 2026-02-25 06:16:38 | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Contact Rating @ Voltage | |
| Illumination | |
| Industrial Grade | |
| Ingress Protection | |
| Key Color | |
| Key Type | |
| Legend | |
| Legend Type | |
| Matrix (Columns x Rows) | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Keys | |
| Operating Temperature | |
| Output Type | |
| Sealed | |
| Switch Type | |
| Tape & Reel | |
| Termination Style |
The Grayhill 88AB2 is a 12-key keypad switch featuring a polyester overlay key type and interchangeable legend. It utilizes a snap dome switching mechanism and provides a matrix output.
This keypad switch is rated for 0.01A at 24VDC and operates within a temperature range of -40°C to 80°C. It is designed for panel mounting, offering flexibility for front or rear installation, and has an ingress protection rating of IP42.
The 88AB2 boasts a mechanical life of 3,000,000 cycles. Its construction is sealed and splash-proof, making it suitable for various applications where environmental resistance is important. The legend is customizable and sold separately.
Typical applications for this type of keypad include transportation equipment, healthcare equipment, fitness equipment, avionics, ATMs, kiosks, security systems, and industrial controls.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.75 | $0.75 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The Grayhill 88AB2 keypad switch has 12 keys.
The 88AB2 keypad has a 3x4 matrix configuration.
The operating temperature range for the 88AB2 keypad switch is -40°C to 80°C.
The 88AB2 keypad switch has a mechanical life rating of 3,000,000 cycles.
The 88AB2 keypad switch has an ingress protection rating of IP42.
The 88AB2 keypad uses a snap dome switch type.
