87220-6 TE Connectivity 87220-6 is a 6-position unshrouded male pin header with a 2.54mm pitch, designed for through-hole mounting.
Mfr Part #:

87220-6

Available from 1 distributors
Mfr Name: TE Connectivity
TE Connectivity
TE Connectivity 87220-6 is a 6-position unshrouded male pin header with a 2.54mm pitch, designed for through-hole mounting.
✓ Total Stock: 70 pcs
$ Price Range: $1.91 - $3.49

87220-6 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Speed Components Ltd ✓
Non-Authorised Inventory information
70 pcs
On Request
70 pcs On Request 1 On Request On Request 2143 On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

87220-6 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Length
Contact Material
Contact Shape
Contact Type
Current Rating (Amps)
Fastening Type
Insulation Color
Insulation Height
Insulation Material
Lead Spacing
Lead Style
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Overall Contact Length
Pitch
Shrouding
Style
Termination
View Similar Products (0)

87220-6 Description

Short technical summary and product information.

The TE Connectivity 87220-6 is a 6-position, single-row, unshrouded header connector featuring male pin contacts on a standard 2.54mm pitch. It is designed for through-hole solder termination, making it suitable for board-to-board or cable-to-board applications.



This connector uses phosphor bronze contacts with a 30 microinch gold finish for reliable electrical performance. The square pin contacts have a contact length of 8.08mm and an overall contact length of 13.55mm. The black thermoplastic insulator is rated UL94 V-0 for flammability.



Rated for 3A current and an operating temperature range of -65b0C to 105b0C, this push-pull style header is ideal for general-purpose interconnection in a variety of electronic assemblies.

87220-6 Quick Information

Product Type: Header Connector
Canonical Name: TE Connectivity 87220-6 Header, Male Pins, 6 Position, 1 Row, 2.54mm Pitch, Through Hole, Unshrouded
Subcategory: Unshrouded Male Pin Header

87220-6 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: Non-Compliant

87220-6 Estimated Pricing

Qty Low High
1+ $3.49 $3.49
10+ $2.97 $2.97
240+ $2.37 $2.37
720+ $2.19 $2.19
1,200+ $2.11 $2.11
5,040+ $1.91 $1.91

Estimated market price range - modelled values for guidance only, not live distributor offers.

87220-6 Features

  • 6-position single-row male pin header.
  • 2.54mm pitch for standard applications.
  • Through-hole solder mounting type.
  • Gold-plated phosphor bronze contacts.
  • UL94 V-0 rated thermoplastic insulator.

87220-6 Applications

  • Board-to-board interconnection solution.
  • Cable-to-board connector system.
  • General purpose electronic assemblies.
  • Embedded system expansion headers.

87220-6 FAQs

5 frequently asked questions generated from this part’s specifications.
What is the pitch of the TE Connectivity 87220-6 header?

The pitch is 2.54mm (0.100").

How many positions does the 87220-6 connector have?

It has 6 positions in a single row.

What is the current rating of this header?

The current rating is 3A.

What is the mounting type for the 87220-6?

It is a through-hole mounting connector with solder termination.

Is the TE Connectivity 87220-6 RoHS compliant?

RoHS3 compliant status is listed but unverified; treat as low confidence.
