| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
480 pcs
|
480 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| Current Rating (Amps) | |
| DC Resistance (DCR) | |
| Height | |
| Inductance | |
| Inductance Test Frequency | |
| Length | |
| Material | |
| Mounting Type | |
| Operating Temperature | |
| Shielding | |
| Tolerance | |
| Width |
The 8532R-07L from API Delevan Inc. is a fixed inductor with a nominal inductance of 3.3 µH and a tolerance of ±15%. It is rated for a continuous current of 4.7 A and has a maximum DC resistance (DCR) of 16 mOhm, which helps minimize power loss.
This inductor operates across a wide temperature range from -55°C to 125°C, making it suitable for various demanding environments. It features a ferrite core material and is unshielded. The component's dimensions are 21.84mm in length, 8.12mm in width, and a maximum height of 7.26mm. It utilizes a nonstandard package and is designed for surface mount installation.
Key electrical specifications include a saturation current of 3.5 A and an inductance test frequency of 1 kHz. The nonstandard package dimensions should be considered for PCB layout and thermal management.
The inductance of the 8532R-07L is 3.3 µH.
The 8532R-07L has a current rating of 4.7 A.
The DC Resistance (DCR) of the 8532R-07L is 16mOhm Max.
The 8532R-07L uses a Nonstandard package.
The 8532R-07L has a length of 21.84mm, a width of 8.12mm, and a height of 7.26mm.
The operating temperature range for the 8532R-07L is -55°C to 125°C.
The saturation current of the 8532R-07L is 3.5 A.
