852-80-010-10-001101 2-row, 10-position unshrouded male pin header with 1.27mm pitch, through-hole solder termination, rated for 1A and 150VDC.
Mfr Part #:

852-80-010-10-001101

Available from 1 distributors
Mfr Name: Preci-Dip
Preci-Dip
2-row, 10-position unshrouded male pin header with 1.27mm pitch, through-hole solder termination, rated for 1A and 150VDC.
✓ Total Stock: 10 pcs
$ Price Range: $1.04 - $2.70

852-80-010-10-001101 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Speed Components Ltd ✓
Non-Authorised Inventory information
10 pcs
On Request
10 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

852-80-010-10-001101 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Length
Contact Material
Contact Shape
Contact Type
Current Rating
Current Rating (Amps)
Fastening Type
Insulation Color
Insulation Height
Insulation Material
Lead Style
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Overall Contact Length
Pitch
Row Spacing
Shrouding
Style
Termination
Termination Style
Voltage Rating
View Similar Products (0)

852-80-010-10-001101 Description

Short technical summary and product information.

The Preci-Dip 852-80-010-10-001101 is a 10-position, 2-row male pin header designed for board-to-board applications. It features a 1.27mm (0.050") pitch and 0.050" row spacing, enabling high-density interconnections. The through-hole mounting with solder termination ensures reliable mechanical and electrical connections. Contacts are made of brass with a tin finish, and the insulation is black glass-filled PCT/Polyester (UL94 V-0). The unshrouded header uses a push-pull fastening mechanism. Rated for 1A per contact and 150VDC, it operates over a temperature range of -55°C to 125°C. The overall contact length is 0.319" (8.10mm) with a contact length of 3.00mm and insulation height of 1.90mm. This header is suitable for various electronic assemblies requiring a compact, reliable interconnect.

852-80-010-10-001101 Quick Information

Product Type: Header, Male Pins
Series: 852
Canonical Name: Preci-Dip 852-80-010-10-001101 10-Position 1.27mm Pitch Through Hole Male Pin Header
Subcategory: Male Pins

852-80-010-10-001101 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

852-80-010-10-001101 Estimated Pricing

Qty Low High
1+ $2.70 $2.70
10+ $2.36 $2.36
25+ $1.93 $1.93
100+ $1.62 $1.62
480+ $1.24 $1.24
960+ $1.12 $1.12
2,880+ $1.05 $1.05
5,280+ $1.04 $1.04

Estimated market price range - modelled values for guidance only, not live distributor offers.

852-80-010-10-001101 Features

  • 10-position, 2-row male pin header.
  • 1.27mm pitch for high-density designs.
  • Through-hole solder termination.
  • Rated for 1A and 150VDC.
  • Operating temperature -55°C to 125°C.

852-80-010-10-001101 Applications

  • Board-to-board stacking in compact devices.
  • Prototyping and test fixture connections.
  • Industrial control and automation systems.
  • Consumer electronics interconnects.

852-80-010-10-001101 FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does this header have?

10 positions, all loaded.

What is the pitch of this connector?

1.27mm (0.050").

What is the current rating per contact?

1A.

What is the voltage rating?

150VDC.

What is the mounting type?

Through hole with solder termination.

What is the operating temperature range?

-55°C to 125°C.

What is the contact finish?

Tin.
