| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
5 pcs
|
5 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating | |
| Current Rating (Amps) | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Operating Temperature Range | |
| Overall Contact Length | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Termination | |
| Voltage Rating |
The Preci-Dip 852-80-008-10-001101 is an 8-position unshrouded male pin header featuring a 1.27mm (0.050") pitch and two rows. This board-to-board style connector is designed for through hole mounting and solder termination.
The connector uses circular brass contacts with a tin finish and an overall contact length of 8.10mm (0.319"). The black insulator is made from PCT, polyester, glass filled material with a UL94 V-0 flammability rating. The push-pull fastening type allows for simple mating and unmating.
Rated for 1A current and 150VDC, the operating temperature range spans -55°C to 125°C. The component is RoHS3 compliant and has an MSL of Level 1 Unlimited.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.17 | $2.17 |
| 10+ | $1.90 | $1.90 |
| 25+ | $1.81 | $1.81 |
| 100+ | $1.69 | $1.69 |
| 250+ | $1.53 | $1.53 |
| 600+ | $1.41 | $1.41 |
| 1,200+ | $0.96 | $0.96 |
| 5,400+ | $0.95 | $0.95 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The pitch is 1.27mm (0.050").
The current rating is 1A and the voltage rating is 150VDC.
It has 8 positions in 2 rows.
Through hole.
